Eujgoov LAN Cable Ethernet Tester + Multimeter, RJ45 RJ11 Wire Tracker 400M Length Testing POE NCV Detection Port for Scanning Network

Specification: Item Type: Network Cable Tester Battery: ABS Host Battery: 1 x 1250mAh rechargeable li battery (built in) Line Finding Pen Battery: 1 x 6F22 550mAh dry battery (equipped) Length Measurement: 2.5-400M Ethernet cable, 200m reference Crystal Head Crimp Test: Yes Line Finding Function: Digital/vibration Line Pairing Function: Normal/short circuit/open circuit/crossover Short Circuit On/Off: Multimeter measurement Switch Port Flashing: 10M/100M/1000M Live POE Switch: Yes Voltage (Battery): Multimeter measurement POE Polarity: Standard/non standard, POE voltage/polarity (5-60V) ID Pairing Function: Optional adapter accessory (shipped without adapter) Input Instructions: Yes NCV Function: Multimeter measurement Other Functions: Host lighting function, multimeter probe prompt function, VA display, white light flashlight function, adjustable digital line finding sensitivity, low voltage detection Multimeter Function: DC Voltage: 600.0mV~1000V ±(0.5%+3) AC Voltage: 6V~600V ±(1%+3) DC Current: ​.9mA~9.​A ±(1.2%+3) AC Current: ​.9mA~9.​A ±(1.5%+3) Resistor: 600.0Ω~60.00MΩ ±(1.5%+5) Capacitor: 6.000nF-666.6uF ±(2.0%+6) On Off Buzzing: 6.000mF-60.00mF ±(5%+20) Diode: NCV: Level 0-4 Live Detection: Single probe ACV How to Use: Take out the product, turn on the switch to use. packing list: 1 x Network Cable Tester 1 x Line Finder 1 x Instruction Manual 2 x Test Cable 1 x USB Cable 1 x Battery 1 x Storage Bag 2 x Test Pen

• Three Tracking Modes: The Ethernet cable tester kit provides AC filter and analog signal, with three cable tracking modes to choose from: normal mode, anti interference mode, and PoE mode
• POE NCV Test: The Ethernet tester can determine which pins are supplying power and detecting voltage, determine the PSE type (according to af standards), and detect whether there is AC voltage (50V to 1000V), can also test the physical status of and UTP network cables
• Network Cable Tester: The tester features functions such as CONT, power supply, 400 meter line measurement, port tracking, no fault scanning, loopback testing, LED light. Compatible with cables such as CAT5, CAT5e, CAT6, and CAT6A
• Port Flashing: The network tester has anti interference line finding function, which can locate the network port through indicator light flashing, and quickly find the network cable on the switch or router, can be used for 10M, 100M, 1000M hub or switch
• Multimeter Function: The multimeter can measure up to 1000V DC voltage and 600V AC voltage, 10A AC DC current, and 60M resistor, can also test capacitor, wire continuity, diodes, and continuity
• Rechargeable Design with Complete Accessories: Includes built-in 1250mAh rechargeable lithium battery for the host unit, USB charging cable, line finder with battery, test cables, test pens, instruction manual, and convenient storage bag for organized portability
• Advanced Detection Features: Equipped with digital and vibration line finding function, crystal head crimp testing, short circuit and open circuit detection, adjustable sensitivity, white light flashlight function, and low voltage detection capabilities for comprehensive network troubleshooting
